5″ x 1.25″ Ergonomic Orange Polyurethane on Polyolefin Wheel – Precision Bearing

$18.88

PN: ERGX5X1.25PS
In Stock
Please select any add ons you require for your caster and if you are selecting multiple option types, add all of the quantity for the first choice and then make your selections for the second, third, fourth, etc… choices. (Example: 2 With Brakes and 2 Without Brakes)

This option adds a metal spanner bushing to the order, reducing the wheels Inner Diameter to 5/16″ to accomdate a 5/16″ axle

NoneSB5/16 | SB5/16" x 3/8" x 1-5/8" +$1.00
Volume Pricing on Inquiry. Call us: 800-501-3808

View cart Request for Quote

Technical Specifications

5
Wheel Diameter
5
Ollie Recommends!
Caster City Recommendation
Ollie Recommends!
Yes
Non-Marking
Yes
80A
Durometer
80A
1 1/4
Wheel Width
1 1/4
Precision Sealed
Wheel Bearing
Precision Sealed
375 lbs
Maximum Capacity (lbs)
375 lbs
Orange
Color
Orange
Weight
Weight
0.5 lbs

Description

ERGX Wheel: 1.25″ Wide Ergonomic Polyurethane Industrial Caster Wheel

The ERGX Wheel is a 1.25″ wide industrial caster wheel designed for smooth, quiet, and efficient movement. Its vibrant orange, injection-molded polyurethane tread is mechanically bonded to a lightweight polyolefin center for excellent durability and strength. The 80A polyurethane is soft and bouncy, like a tennis ball, reducing push-pull forces to make starting from a stop or changing directions easier while using less energy to keep rolling. Dual precision sealed ball bearings in the hub ensure quiet, low-maintenance operation. Compared to gray rubber wheels, the ERGX Wheel rolls more easily on smooth floors, making it ideal for research laboratories, hospitals, food service, schools, bakeries, and other institutional settings.

This wheel outperforms rubber in many ways. Its polyurethane tread resists grease, oil, cutting, chunking, abrasive wear, and many chemicals and solvents, making it suitable for nearly any factory floor. The ergonomic crown tread design improves maneuverability and reduces friction for smoother rolling. The ERG Wheel is perfect for industrial carts, dollies, and equipment in warehouses, manufacturing plants, or institutional environments, where it reduces operator fatigue and boosts efficiency.

Note that the bonding agent securing the polyurethane tread to the polyolefin center may be affected by certain chemicals, impact, overloading, or heat buildup, similar to mold-on rubber wheels. The ERGX Wheel is not suited for applications involving shock, abuse, obstructions, poor floors, or storage (standing) loads. With proper use, the ERGX Wheel combines advanced materials, ergonomic design, and robust construction for reliable, energy-efficient mobility in demanding environments.



Key Features:

  • Self-Energizing: The resilient nature of this extra-soft polyurethane tread means that it helps push itself along while under load.  It is a mildly self-energizing wheel that helps to reduce the force needed to start and maintain momentum.
  • Material: High-quality 80A polyurethane tread, mechanically bonded to a lightweight polyolefin center for exceptional strength and resilience.
  • Ergonomic Crown Tread: The soft, bouncy polyurethane (comparable to a tennis ball) reduces push-pull forces, making directional changes from a standstill effortless and minimizing energy needed to maintain momentum.
  • Superior to Rubber: Polyurethane offers excellent resistance to grease, oil, cutting, chunking, and abrasive wear, ensuring long-lasting performance on nearly any factory floor.
  • Dual Precision Sealed Ball Bearings: Integrated into the hub for quiet operation, low maintenance, and smooth, efficient rolling.
  • Applications: Ideal for industrial carts, dollies, and equipment in warehouses, manufacturing facilities, and other settings requiring reliable mobility and reduced operator fatigue.
  • Note: As with mold-on rubber wheels, the bonding agent securing the polyurethane tread to the polyolefin center may be affected by exposure to certain chemicals, impact, overloading, or heat buildup. Proper use ensures optimal durability.

The ERGX Wheel combines ergonomic design, advanced materials, and robust construction to deliver unmatched performance and efficiency in industrial applications.
