Name: 6" Green Polyurethane on Iron Wheel - Model 9 Rigid Caster
SKU: 9PY6X2-R
Availability: InStock

1 +

Volume Pricing on Inquiry. Call us: 800-501-3808

Most of our casters are assembled and dispatched within 24-48 hours.

Click to Download CAD Files

Download STP File Download 2D File

6″ Green Polyurethane on Iron Wheel – Model 9 Rigid Caster

$47.90

PN: 9PY6X2-R

In Stock

Please select any add ons you require for your caster and if you are selecting multiple option types, add all of the quantity for the first choice and then make your selections for the second, third, fourth, etc… choices. (Example: 2 With Brakes and 2 Without Brakes)

SKU: 9PY6X2-RCategories: Plate Casters, Rigid Casters, Model 9 - Up To 1,200lbs each - Plate Size 4" x 4-1/2", Model 9 Rigid

Technical Specifications

Wheel Diameter

Caster City Recommendation

Ollie Recommends!

Non-Marking

Yes

ISO 9001

ISO 9001:2015 Certified

Wheel Core Material

Iron

Fork Finish

Zinc Coating

Wheel Width

Wheel Bearing

Roller

Maximum Capacity (lbs)

900 lbs

Overall Height

7-1/2"

Plate Fastener Type

Mounting Plate, Top Plate

Plate Mounting Type

Top Plate

Weight

8.25 lbs

Description

The Rigid Model 9 Caster is the matching rigid caster for the Model 9 Swivel. When hand moving equipment on 4 swivel casters it can be tough to control directional travel. Rigid casters assist in controlling the direction when equipment is being moved in a direct line. Equipment with rigid casters installed can not travel sideways. Rigid casters are typically placed at the opposite end from the push handle. The legs are 1/4″ thick and the 1/2″ diameter axle is sized for wheels with a 2 7/16″ hub width. This caster is constructed from stamped steel. Rigid casters carry more weight than swivels because they do not have an offset, but on our website both rigid and swivel casters are displayed with the same capacity. Ideal for commercial laundry operations, dry cleaning facilities, and linen services. Additional plate sizes and bearing types can be supplied on request. A 304 Stainless Steel version is also manufactured for washdown and corrosive environments.

The polyurethane caster wheel outperforms rubber in resistance to grease, oil, cutting, chunking, and abrasive wear. Available in green (PY) or red (PYR) polyurethane tread bonded to a durable iron core, these wheels are designed for versatility and can be used on nearly any factory floor. With a tire hardness of 90â€”95 Durometer (Shore A), they provide excellent durability. These polyurethane caster wheels maintain a temperature range of -20°F to 180°F. The principle benefit of a polyurethane wheel over the same size rubber wheel is increased capacity. Given a manual operation under ideal conditions, polyurethane caster wheels have a safe operating capacity of up to three times the capacity of the same size rubber wheel. Given the same size load on a smooth floor, a polyurethane caster wheel rolls easier than the same size conventional rubber caster wheel. However, when used at full capacity, polyurethane is not easy rolling. The bonding agent which holds the polyurethane tire to its iron center can be affected by exposure to some chemicals, impact, overloading, and the buildup of heat. The polyurethane caster wheel is compatible with precision sealed ball bearings, roller bearings. Ideal for aircraft maintenance stands, turbine handling, and nuclear facility equipment.

*This Plate Caster Model 9 contains the Green Polyurethane on Iron with Roller Bearings in the Wheel.

The Photo Displayed on CasterCity.com is the 6″ Caster Wheel.

For more information and help placing an order, give us a call at 800-501-3808.

FAQ

“PY” Standard Duty Polyurethane on Iron Wheel

What is the Polyurethane on Iron wheel made of?
Polyurethane tire (90-95 Durometer, Shore A) on an iron core.

What’s the load capacity of the Polyurethane on Iron wheel?
Varies by size—check ratings and pick higher than your load.

What are the benefits of the standard duty Polyurethane on Iron wheel?
Inexpensive initial cost, Resists grease, oil, cutting, and wear. Rolls easier than rubber on smooth floors.

What are the downsides?
Not for shock, overloading, rough floors, or storage loads. Tough to roll at full capacity.

Where does it work best?
Warehouses, manufacturing, food processing, retail, and institutional settings.

Can it handle wet areas?
Yes, but avoid chemicals that harm the bonding agent.

How’s it on floors?
Better than metal, not as soft as rubber—some deflection under load.

What’s the temperature range?
-20° to 180° F.

Need more info?
Contact Caster City at 800-501-3808 or sales@castercity.com.

Application Use

Application Use Plate Industrial Caster Model 9:

The Plate Model 9 is designed for medium to heavy-duty jobs and are built for floor protection, mobility, and ergonomic effectiveness in a variety of industries, such as:

Manufacturing Industry

Assembly line carts
Tool carts and cabinets
Workbenches
Assembly stations
Die and mold carts
Material handling carts
Engine stands
Transmission jacks
Wing assembly jigs

Warehousing and Distribution

Stock picking carts
Shipping and receiving carts
Flatbed carts
Dollies
Mobile shelving units

Automotive Industry

Vehicle assembly line equipment
Parts transport carts
Tool chests
Battery carts
Mobile diagnostic equipment

Aerospace Industry

Aircraft maintenance platforms
Engine transport dollies
Wing and fuselage assembly jigs

Food Processing and Service

Ingredient bins
Mixing bowls on stands
Oven racks
Bakery carts
Kitchen carts
Serving trolleys
Laundry carts

Healthcare

Hospital beds
Medical carts
Mobile diagnostic machines

Retail

Mobile display racks
Shelving units
Point-of-purchase displays
Shopping carts

Construction and Maintenance

Mobile scaffolds
Work platforms
Tool carts
Generator carts
Compressor carts

Agriculture

Farm machinery parts transport carts
Greenhouse carts

Marine

Boat mold transport carts
Deck equipment movement

Data Centers and IT

Server rack carts
Mobile cabinets

Entertainment and Events

Stage equipment carts
Lighting and sound equipment stands
Mobile platforms

Laboratories

Lab carts
Equipment stands

Printing and Publishing

Paper roll carts
Printing press component transport

Textile Industry

Fabric roll carts
Sewing machine stands

Chemical Industry

Drum dollies
Cylinder carts

HVAC and Electrical

HVAC equipment carts
Electrical panel carts

Woodworking and Metalworking

Mobile worktables
Saw stands
Material handling carts

Waste Management

Waste containers on wheels
Recycling bins

Fitness Centers

Mobile weight racks
Equipment stands

Transportation Hubs

Baggage carts
Luggage carts

Cold Storage and Refrigeration

Refrigerated warehouse carts
Food processing plant equipment

Our #1 goal is to help you find the best caster and wheels for your needs. If you need help finding the right casters, contact our team of professionals. You can also customize many of our casters with a variety of options such as swivel locks, wheel brakes and zerk fittings. We ship our products from assembly plants in Georgia, Pennsylvania, Virginia, Texas, Nevada and Canada. Whether you’re a one-man shop or a global giant, we can provide you with: We specialize in Business to Business, however, consumer orders are gladly accepted and we can provide you with:

Fastest Lead Time in the Industry
Caster performance data.
Comparative data.
Customized caster solutions.
Help with caster solutions.
Case studies by industry or application.
Manufacturer and Distributor of over $25 million dollars in Finished Component Parts
Majority of Orders Processed and Shipped in 2 Days or Less

Call us during the design phase of your project, we can help you avoid costly modifications once fabrication has started. We guarantee what we recommend.
